ZFW6125 Explosion-Proof Panoramic Mobile Lighting System
A panoramic mobile light on a tripod mast: spot and flood together, stepless dimming and a yellow warning light. DC 22.2 V, 15 Ah, IP66 — five hours or more on ultra-strong and fourteen hours or more on working light. It folds to 983 mm and raises to 2 260 mm, at 8 ±0.5 kg.
- DC 22.2 V
- 15 Ah
- IP66
- spot + flood
- ≥5 h – ≥14 h
- 8±0.5 kg
- Rated voltage — DC22.2V
- Rated capacity — 15Ah
- Protection grade — IP66
- Dimensions — Folded 166×157×983mm (±50)
- Weight — 8±0.5kg
Technical data
| Parameter | Value |
|---|---|
| Rated voltage | DC22.2V |
| Rated capacity | 15Ah |
| Protection grade | IP66 |
| Lighting mode | Spot + Flood |
| Warning light colour | Yellow |
| Brightness adjustment | Steps + Stepless Dimming |
| Working time | Ultra-Strong ≥5h, Strong ≥10h, Working ≥14h |
| Dimensions | Folded 166×157×983mm (±50) |
| Raised 872×758×2260mm (±50) | |
| Weight | 8±0.5kg |
Features
- Rechargeable: a 15Ah battery, a DC22.2V supply.
- Ingress protection IP66.
- Built-in yellow warning light.
- Dimensions Folded 166×157×983mm (±50), 8±0.5kg.
- Folding tripod mast: 983 mm folded, 2 260 mm raised.
- Spot and flood together, with stepped and stepless dimming and a yellow warning light.
Where it is used
Temporary and portable lighting tasks in industrial plants: inspection rounds, shutdown and turnaround work, tank and vessel cleaning, cable and pipe routing, spill response, and any position where a fixed luminaire is not practical.
Need a quotation for the ZFW6125?
Tell us the area classification, how long the light has to run on one charge and how it will be mounted, and our engineers will confirm the configuration and prepare the quotation for you.
The manufacturer’s sheet for this model does not state an Ex marking. Portable work lights for hazardous areas are specified against the area classification on site — send us the zone, the gas or dust group and the temperature class you need, and our engineers will confirm the marking and the correct model before you order. Technical data is reproduced from the manufacturer’s sheet for model ZFW6125. Dimensions are given in millimetres unless stated otherwise.
