ZSFW6179 Self-Loading Mobile Charging Cabin
A self-loading cabin built around a 700 W to 20 kW generator for charging and power supply on site, with two to eight LED lamps on a mast reaching 3 m to 10 m. Gel, LiFePO4, lead-acid or AGM battery, touch-screen control and wireless remote — 650 kg.
- generator 700 W–20 kW
- mast 3–10 m
- LED to 1000 W
- IP65
- touch screen
- 650 kg
- Lighting system — Rated power — 50/100/150/200/300/400/500/1000W
- Lighting system — Light source — LED Lamps
- Lighting system — Protection grade — IP65
- Dimensions — 2700×1750×1700mm
Technical data
| Parameter | Value |
|---|---|
| Lighting system — Light source | LED Lamps |
| Lighting system — Rated power | 50/100/150/200/300/400/500/1000W |
| Lighting system — Input voltage | AC220V |
| Lighting system — Protection grade | IP65 |
| Lighting system — No. of lamps | 2 / 4 / 6 / 8 |
| Lifting system — Mast | Electric / Pneumatic / Hydraulic |
| Lifting system — Lifting height | 3 / 4.5 / 5 / 6 / 7 / 9 / 10m |
| Lifting system — Mast material | Carbon Steel, 304 SS, Aluminum Alloy |
| Lifting system — Mast surface colour | Black, White, Natural Metal |
| Power system — Generator type | Gasoline / Diesel |
| Power system — Starting mode | Manual / Electric |
| Power system — Cooling mode | Air / Water Cooled |
| Power system — Generator power | 700W/1000W/2000W/3000W/5000W/8kW/10kW/20kW |
| Power system — Output voltage | AC220V / AC380V |
| Power system — Battery | Gel, LiFePO4, Lead-Acid, AGM |
| Control system — Control panel | Breaker, Rotary Handle, Touch Screen |
| Control system — Remote control | Wireless Remote |
| Chassis system — Material | Carbon Steel, 304 Stainless Steel |
| Chassis system — Support legs | Electric / Hydraulic |
| Chassis system — Self-levelling system | Yes/No |
| Chassis system — Mobility | 2″ Fixed Caster, 2″ Swivel Caster |
| Dimensions | 2700×1750×1700mm |
| Total weight | 650kg |
Features
- Rated power 50/100/150/200/300/400/500/1000W.
- Ingress protection IP65.
- Dimensions 2700×1750×1700mm.
- Charging and power supply for tools, batteries and equipment on site.
- Touch-screen control panel, wireless remote, self-levelling support legs.
Where it is used
Temporary and portable lighting tasks in industrial plants: inspection rounds, shutdown and turnaround work, tank and vessel cleaning, cable and pipe routing, spill response, and any position where a fixed luminaire is not practical.
Need a quotation for the ZSFW6179?
Tell us the area classification, how long the light has to run on one charge and how it will be mounted, and our engineers will confirm the configuration and prepare the quotation for you.
The manufacturer’s sheet for this model does not state an Ex marking. Portable work lights for hazardous areas are specified against the area classification on site — send us the zone, the gas or dust group and the temperature class you need, and our engineers will confirm the marking and the correct model before you order. This is a configurable system: generator size, mast type and lamp count are selected to order. Tell us the load you need to supply and our engineers will configure it. Technical data is reproduced from the manufacturer’s sheet for model ZSFW6179. Dimensions are given in millimetres unless stated otherwise.
