ZSFW6178 Self-Loading Mobile Drainage Cabin
A self-loading cabin that combines a lighting mast with a drainage pump: 350 m³/h to 500 m³/h at 15 kW or 30 kW, a 50 m hose, an 8 kW to 50 kW generator and two to eight LED lamps on a mast up to 6 m — 800 kg.
- pump 15–30 kW
- 350–500 m³/h
- 8–50 kW generator
- mast to 6 m
- IP65
- 800 kg
- Lighting system — Rated power — 50/100/150/200/300/400/500/1000W
- Lighting system — Light source — LED Lamps
- Lighting system — Protection grade — IP65
- Dimensions — 2800×1700×1750mm
Technical data
| Parameter | Value |
|---|---|
| Lighting system — Light source | LED Lamps |
| Lighting system — Rated power | 50/100/150/200/300/400/500/1000W |
| Lighting system — Input voltage | AC220V |
| Lighting system — Protection grade | IP65 |
| Lighting system — No. of lamps | 2 / 4 / 6 / 8 |
| Lifting system — Mast | Electric / Pneumatic / Hydraulic |
| Lifting system — Lifting height | 3m / 4.5m / 5m / 6m |
| Lifting system — Mast material | Carbon Steel, 304 SS, Aluminum Alloy |
| Lifting system — Mast surface colour | Black, White, Natural Metal |
| Power system — Generator type | Gasoline / Diesel |
| Power system — Starting mode | Manual / Electric |
| Power system — Cooling mode | Air / Water Cooled |
| Power system — Generator power | 8000W/10000W/20000W/42000W/50000W |
| Power system — Output voltage | AC220V / AC380V |
| Power system — Battery | Gel, LiFePO4, Lead-Acid, AGM |
| Drainage system — Pump power | 15kW / 30kW |
| Drainage system — Pump flow | 350m³/h / 500m³/h |
| Drainage system — Hose length | 50m |
| Control system — Control panel | Breaker, Rotary Handle, Touch Screen |
| Control system — Remote control | Wireless Remote |
| Chassis system — Material | Carbon Steel, 304 Stainless Steel |
| Chassis system — Support legs | Electric / Hydraulic |
| Chassis system — Self-levelling system | Yes/No |
| Chassis system — Mobility | Yes/No |
| Dimensions | 2800×1700×1750mm |
| Total weight | 800kg |
Features
- Rated power 50/100/150/200/300/400/500/1000W.
- Ingress protection IP65.
- Dimensions 2800×1700×1750mm.
- Combines a drainage pump with a lighting mast in one self-loading cabin.
- Touch-screen control panel, wireless remote, self-levelling support legs.
Where it is used
Temporary and portable lighting tasks in industrial plants: inspection rounds, shutdown and turnaround work, tank and vessel cleaning, cable and pipe routing, spill response, and any position where a fixed luminaire is not practical.
Need a quotation for the ZSFW6178?
Tell us the area classification, how long the light has to run on one charge and how it will be mounted, and our engineers will confirm the configuration and prepare the quotation for you.
The manufacturer’s sheet for this model does not state an Ex marking. Portable work lights for hazardous areas are specified against the area classification on site — send us the zone, the gas or dust group and the temperature class you need, and our engineers will confirm the marking and the correct model before you order. This is a configurable system: pump power, generator size, mast type and lamp count are selected to order. Tell us the flow rate and head you need and our engineers will configure it. Technical data is reproduced from the manufacturer’s sheet for model ZSFW6178. Dimensions are given in millimetres unless stated otherwise.
